More ways to shoot with your SIGMA fp: custom recording formats, lossless CinemaDNG, motion data for Gyroflow, RAW monitoring and screen flip. Pick the tools you want in fpSup-Merge and load them from the SD card.

讓 SIGMA fp 有更多拍攝方式:自訂錄影格式、無損 CinemaDNG、 Gyroflow 防震資料、RAW 監看與螢幕翻轉。 在 fpSup-Merge 勾選需要的功能,從 SD 卡載入。

Discord Telegram 群 YouTube supMe on Ko-fi在 Ko-fi 支持我

Camera compatibility相機相容性

Camera相機
SIGMA fp only. Not the fp L — it has a different sensor, and nothing here works on it.
只限 SIGMA fp。不是 fp L —— 它的感光元件不同, 這裡的東西在它上面都不能用。
Firmware韌體
Ver.5.02 only — not “5.02 or newer”. The card writes to fixed addresses in Ver.5.02; on any other version those addresses are wrong. Check in MENU → SYSTEM → Information.
只限 Ver.5.02 —— 不是「5.02 或更新」。 卡片寫入的是 Ver.5.02 裡的固定位址,換了版本位址就是錯的。
在 MENU → SYSTEM → Information 確認。
Loading載入方式
The current fpSup-Merge card loads tools into memory from AutoRun.txt and the fpSup folder on the SD card. It does not write to the camera's flash. Installation and removal instructions.
目前的 fpSup-Merge 卡片透過 SD 卡上的 AutoRun.txt 和 fpSup 資料夾,把功能載入記憶體,不寫入相機的 flash。 安裝與移除說明。

Start開始

Choose your tools in fpSup-Merge在 fpSup-Merge 選擇功能 Pick what you want on one card, download the zip and follow the install steps. 勾選要放進同一張卡的功能,下載 zip,照頁上的步驟安裝。

First time? Read the setup guide, including how to remove the tools.

第一次使用?先看使用指南,也包括怎麼移除。

What you can add可以加入的功能

Choose the tools for your workflow. Each guide covers its settings, requirements and what has been tested; fpSup-Merge shows the current versions.

依照拍攝流程選擇功能。各功能指南有設定、使用條件與測試紀錄; 目前版本在 fpSup-Merge 裡查看。

Res-Custom · recording formatsRes-Custom · 錄影格式 OG2K, OG3K, OG3.5K, OG4K and S16 on one card, selected in Settings and Quick Set. OG2K、OG3K、OG3.5K、OG4K 與 S16 放在同一張卡,在 Settings 和 Quick Set 選擇。 Lossless · CinemaDNG compressionLossless · CinemaDNG 無損壓縮 Record lossless-compressed CinemaDNG with the camera's own hardware codec. 用相機內建的硬體編碼器錄無損壓縮 CinemaDNG。 Gyro2 · motion data for stabilisationGyro2 · 防震運動資料 Motion data inside every CinemaDNG frame, used with the Gyroflow (fpSup) plugin to stabilise footage in DaVinci Resolve. 運動資料直接寫進每一格 CinemaDNG,搭配 Gyroflow(fpSup)外掛在 DaVinci Resolve 裡防震。 RAW-View · RAW monitoringRAW-View · RAW 監看 Monitor the RAW about to be recorded in 12-bit CinemaDNG, including where highlights clip. 監看 12-bit CinemaDNG 即將錄下的 RAW,看清高光在哪裡過曝。 ScreenFlip · screen orientationScreenFlip · 螢幕方向 Rotate the rear screen 180°, mirror it, or both, with a choice for each display mode. 背螢幕翻轉 180°、左右鏡像,或兩者一起;各顯示模式可以分別設定。

In development: Split Record, HDRx, LUT preview and AF optimisation. See their status in fpSup-Merge.

開發中:Split Record、HDRx、LUT 預覽與 AF 最佳化。 進度在 fpSup-Merge 裡查看。

For developers, Shell provides commands and memory access over USB. Release notes and older cards.

開發者可使用 Shell 透過 USB 下指令、存取記憶體。版本說明與舊版卡片。

See it working看它運作

SIGMA fp Open Gatethe full 3:2 sensor, recorded完整的 3:2 感光元件,錄下來
Stabilised in Gyroflow用 Gyroflow 穩定no extra hardware, no rig不用額外硬體或支架

Other people's tests別人做的測試

Not ours — footage from people with nothing to sell you.

不是我們拍的 —— 來自沒有要賣你任何東西的人。

Sigma fp — fpSup 3K Open Gatea user's own test of OG3K一位使用者自己做的 OG3K 測試
fpSup-Merge — OG2K + GyroCC FRANK FPV's test of an earlier OG2K + Gyro cardCC FRANK FPV 測試早期的 OG2K + Gyro 合併卡

Tools工具

fpSup-Merge Tick what you want and download one zip for the SD card. 勾你要的，下載一個 zip 放進 SD 卡。 runs in your browser · before you shoot在你的瀏覽器裡執行 · 拍攝前 .GYR converter · older Gyro cards.GYR 轉換器 · 舊版 Gyro 卡片 Turns a raw .GYR file into the .gcsv and .json Gyroflow reads. Only needed if a take left you a .GYR instead of those two files. 把原始 .GYR 轉成 Gyroflow 讀的 .gcsv 和 .json。 只有錄完拿到的是 .GYR、而不是那兩個檔案時才需要。 runs in your browser · after you shoot在你的瀏覽器裡執行 · 拍攝後

Why this is possible為什麼這件事做得到

What AutoRun.txt actually isAutoRun.txt 到底是什麼 The fp has a factory shell with 77 commands, and at startup it runs a script from the SD card without asking. How that became the tools you can use today, and what went wrong on the way. fp 本來就有一個 77 個指令的工廠 shell,開機時會直接執行記憶卡上的腳本, 不經任何確認。
它怎麼變成現在這些拍攝工具,以及途中出過的錯。

Questions, and things that went wrong問題,以及出錯的地方

Bugs, cards that will not start, footage that looks wrong — ask on Discord. New test builds appear there first.

Bug、卡片開不起來、畫面不對 —— 到 Discord 問。新測試版會先發在那裡。

Join the Discord加入 Discord Telegram 群 YouTube

Support the work支持這份工作

One person reading disassembly. Everything here is free and will stay free; Ko-fi pays for the time.

一個人在讀反組譯。這裡的一切都免費,也會一直免費; Ko-fi 支撐的是投入的時間。

supMe on Ko-fi在 Ko-fi 支持我

The research underneath底下的研究

Firmware research韌體研究 How the IMX410's ISO and gain really work, the sensor's readout modes, the USB transport, the firmware map. Each project says what is proven and what is still unknown. IMX410 的 ISO 與增益到底怎麼運作、感光元件的讀出模式、 USB 傳輸、韌體地圖。各專案寫明哪些已證實、哪些還不知道。 for people who want to read, or to help給想讀、或想幫忙的人
